WSE-9838498 (3) Solar Panels with 3 Batteries
WSE-9838498 (3) Solar Panels with 3 Batteries
The WSE-9838498 is a sustainable energy solution designed for use in hazardous environments. The system is equipped with three 200-watt solar panels and three batteries for energy storage. Power is supplied by three 24V-1000AH 8D batteries, ensuring steady and dependable operation for connected devices.
WSE-9838498
Unit Type: Solar energy system
Solar Panel Dimensions: 62.5″ x 31.1″ x 2″
Weight: – 25.0kg
Battery Type: Valve Regulated Lead Acid
Capacity: (3) 250aH 8D 24V
Panel Watts: 600 – (3) 200W Solar Panels
Voltage at Pmax (Vmpp): 38V
Current at Pmax (Impp): 5A
Module Efficiency: 15.2%
Solar Cells: 144 Crystalline 5” Silicon Cells
Mount: Floor or Pole Mount via Rear-access U-bolts (Batteries), Skid Mount Frame Mount
(Solar Panels)
Runtime: (1) 200W 24V Electrical Device – 72 Hrs w/o Sun
Wiring: 40` 14/4 SOOW Cord
Power Warranty 90% 10 years, 80% 25 years
Product Warranty 15 years
Standards Class I, Division 2
Structural Durability Equivalent to roof structure
The WSE-9838498 is a sustainable energy solution designed for use in hazardous environments. The system is equipped with three 200-watt solar panels and three batteries for energy storage. Power is supplied by three 24V-1000AH 8D batteries, ensuring steady and dependable operation for connected devices.
Like all solar-based systems, the charging rate depends on the level of available ambient light. Reduced sunlight—such as indirect exposure or cloudy conditions—will increase the time required to recharge. When fully charged, the system can operate for up to 72 hours without sunlight.
Mechanical Specification
Mounting: During setup, the solar panels can be fastened to flat surfaces using a skid-mounted frame. The battery enclosure may be installed either on the ground or attached to poles with rear-access U-bolts.
Wiring: WSE-9838498 ships with 30 feet of 12/2 SOOW cord. Custom
Applications: remote monitoring stations; oil and gas well sites; refineries; gas processing and compression facilities; chemical and petrochemical plants; water and wastewater treatment facilities; renewable energy sites; pipeline monitoring stations; mining operations; agricultural operations; grain storage and handling facilities; transportation infrastructure; utility substations; and other off-grid or low-access industrial locations.
Type: Emergency Battery Pack
Dimensions: 12.00″ x 12.00″ x 6.00″
